HAZARDOUS LOCATION LED HIGH BAY LIGHTS

CES- EX-GB-02 Series

Features

• Patent designed to be Curved Fin Shape, maximize the best heat transmit.

• Housing - Aluminum alloy (ADC12).

• LED: LM80 certified, high efficacy, low decay, long lifespan.130lm/W ±5, up to 26000lm.

• Lens -tempered glass( 8mm - 10mm)shock & vibration resistant, Super clear,>90% light transmit.

• Meanwell LED Driver,>90% driver efficacy.

• Circuit design: 4KV/6KV Surge Protection power supply. • Power: 30W/40W/60W/80W/100W/120W/150W/185W/200W

Certifications

NEC/CEC:

• Class I, Division 2, Groups A, B, C and D

• Class II, Division 2, Groups F and G

• Class III

• T-Class: T3C/T4/T4A/T5/T6

• Damp and wet locations

• Certification body: UL

• Certification Mark: CUL

Standard :

• US: UL 844; UL 1598

• Canada: CSA C22.2 No. 137; CSA C22.2 No. 250.0

Certifications :
